Choose for the Water
QDX models are designed for clean water. WQD and WQDX models cover water with soft particles within their stated limits.
PLASTIC-HOUSING PUMPS
Plastic Submersible Pumps
Our core compact range for clean and dirty water. Compare water compatibility, performance and configuration options for your market.
Models
Compare the Models
Check the water limits, controls and power options for each model.
QDX-PT · Clean water
QDX-PT
Compact clean-water transfer, with a 7 mm residual water level and manual control.
- Power range
- 200–300 W
- Max. head
- 5–7 m
- Max. flow rate
- 3–5 m³/h
QDX-PH · Clean water
QDX-PH
Bottom-suction clean-water drainage, with a published 7 mm residual water level.
- Power range
- 250–370 W
- Max. head
- 5–8 m
- Max. flow rate
- 5–7 m³/h
QDX-PA · Clean water
QDX-PA
Five power options for clean water, with top-cover and base choices for OEM projects.
- Power range
- 200–750 W
- Max. head
- 5–9 m
- Max. flow rate
- 5–12 m³/h
WQD-PA · Clean & dirty water
WQD-PA
Compact dirty-water drainage with five power options and alternative cover and base designs.
- Power range
- 200–750 W
- Max. head
- 5–9 m
- Max. flow rate
- 5–12 m³/h
WQDX-PA · Clean & dirty water
WQDX-PA
An alternative cover and base design for compact clean-and-dirty-water drainage.
- Power range
- 200–750 W
- Max. head
- 5–9 m
- Max. flow rate
- 5–12 m³/h
QDX-PP · Clean water
QDX-PP
Compact bottom-suction clean-water transfer, with a 10 mm residual level.
- Power range
- 250–370 W
- Max. head
- 6–7 m
- Max. flow rate
- 6–7 m³/h
WQD-PH · Clean & dirty water
WQD-PH
Higher-flow clean-and-dirty-water pumping, with 750 and 900 W options.
- Power range
- 750–900 W
- Max. head
- 10 m
- Max. flow rate
- 15–23 m³/h
WQD-PJ · Clean & dirty water
WQD-PJ
Higher-flow and higher-head options for clean water and soft-particle drainage.
- Power range
- 900–1300 W
- Max. head
- 11–15 m
- Max. flow rate
- 23–28 m³/h
Before You Choose
Before You Choose
Use these points to compare the water, installation and operating requirements before choosing a model.
Compare model water limits, controls and power options, then choose the electrical version, cable, branding and packaging for your distribution or private-label range.
Check the Flow You Need
Compare pump curves at your working head, rather than choosing by wattage alone.
Plan the Product Package
Choose the electrical version, cable, logo and packaging for your distribution or private-label range.
Explore the Applications
Explore portable drainage, tank emptying, pool drainage and rainwater transfer. The right model depends on the water and installation.
Key Applications
Where these families may fit within their published limits.
Application suitability depends on the liquid, solids, required duty point, installation/control method and exact product configuration.
Garden & irrigation
Water-source transfer for garden and small irrigation systems.
Explore applications ↗Drainage
Water removal and transfer applications.
Explore applications ↗Basement & flood drainage
Floodwater removal based on water condition, lift and control requirements.
Explore applications ↗Pool & spa drainage
Dewatering based on chemistry, debris, lift and residual-water targets.
Explore applications ↗Rainwater tank
Rainwater tank and stormwater transfer.
Explore applications ↗Pond & aquaculture
Pond and aquaculture water transfer.
Explore applications ↗Common Questions
Questions to Check Before You Choose
Who manufactures YARDPUMP plastic pumps?
YARDPUMP is the international submersible pump brand of Ningbo Lisheng Pump Co., Ltd., with more than 20 years of pump manufacturing experience.
Can I order these pumps under my own brand?
Yes. Share your quantity, market, electrical requirements and branding or packaging brief. We’ll confirm the available changes and quotation for the selected model.
How do I compare power variants?
Use the performance curve for the flow you need at your working head. Also check water limits, hose size, level control and power supply. A higher wattage does not by itself make a pump the better fit.
